| Type | Gear Ratio | Output Speed (Rpm) |
Torque (Nm) |
Power (Kw) |
Current (A) |
Oil (synthrtic) |
H (For IP21) |
H (For IP55) |
| FT125-5.5 | 24.5 | 39.2 | 1099 | 5.5 | 13 | 460 | 761 | 793 |
| FT125-7.5 | 24.5 | 39.2 | 1499 | 7.5 | 17 | 460 | 761 | 793 |
Motor Parameter Table
| Applied Model |
Model | Power (Kw) |
Pole | Synchronous Speed (rpm) |
Rated Speed (rpm) |
Voltage (V) |
Frequency (Hz) |
Current (A) |
PF. | E.P.(%) | INS.Class | IP Code |
| FT125 | YFD132M1-6B | 5.5 | 6 | 1000 | 960 | 380 | 50 | 13 | 0.78 | 87 | F | IP21/IP55 |
| YFD132M2-6B | 7.5 | 6 | 1000 | 960 | 380 | 50 | 17 | 0.79 | 87 | F | IP21/IP55 |
